PH2.0mm Wafer, Single Row, DIP Straight Type Wafer Connectors

Part No: L104XX-10X1XXX
Mating:
Packing:Bag

Delivery time:7~15 Day

UL: Yes
ROHS Compliant

Inquire Now None

product details

2D(PDF) Drawing

Specifications:

Rating current: 2.0AMP AC/DC
Contact resistance: 20mΩ Max
Withstand voltage: 800V AC/DC
Insulation resistance: 1000mΩ Min
Operation temperature: -25°C to + 85°C
Contact material: Brass
Contact plating: Au or Sn over Ni
Insulator material: PA6T
